90 Degree Flexible Rubber Bent Joint Material Galvanised

Get Latest Price

Min. Order:

Transportation:

Ocean,Land,Air

Port:

Qingdao,Tianjin,Shanghai

Contact Now

 Chat Now

Product Description

Product Attributes
Supply Ability & Additional Information
Packaging & Delivery

< >

Overview

Product Attributes

Brand: Xinhuafeng

Certification: ISO9001

Place Of Origin: China

Processing Service: Moulding

Pressure: High Pressure

Mounting Hole Diameter: 0.25 in

Overall Length: 80~260

Height: 100

Supply Ability & Additional Information

Packaging: wooden case packing

Transportation: Ocean,Land,Air

Supply Ability: 100000 Piece/ per Month

Certificate: ISO9001

Port: Qingdao,Tianjin,Shanghai

Packaging & Delivery

Package Type:: wooden case packing

Picture Example:

Product Summary Elbow Rubber Joint

RUNXING 90 Degree WTX Type Flexible Rubber Bent Joint Material Galvanised Forged Flange is a high-performance pipeline connector, integrating flexibility and corrosion resistance. Made of premium rubber and galvanised forged flange, it effectively absorbs pipeline vibration, reduces noise, and compensates for displacement. As a professional Elbow Rubber Expansion Joint manufacturer, we ensure stable quality, international certification compliance, and customizable solutions to meet global procurement needs.

Product Overview

The 90 Degree WTX Type Flexible Rubber Bent Joint Material Galvanised Forged Flange is a core product of RUNXING, designed for connecting industrial pipelines at 90-degree angles. This Flexible Rubber Bent Joint Material Galvanised combines the flexibility of rubber with the sturdiness of galvanised forged flange, solving problems such as pipeline displacement, vibration, and noise in complex working environments. It is widely recognized by international采购商 for its reliable performance, long service life, and easy installation, making it an essential component in various industrial pipeline systems.

Our product stands out from competitors with strict quality control and advanced production technology, ensuring each90 Degree Flexible Rubber Bent Joint meets international standards and can adapt to harsh working conditions such as high pressure, high temperature, and corrosive media.

Technical Specifications

Product Type: 90 Degree WTX Type Flexible Rubber Bent Joint with Galvanised Forged Flange
Material: Premium synthetic rubber (NBR/EPDM/NR optional), galvanised forged carbon steel flange (SUS304/SUS316 optional)
Nominal Diameter: DN50-DN1200 (customizable)
Working Pressure: 0.6MPa-2.5MPa
Working Temperature: -40℃ to 120℃ (EPDM material up to 150℃)
Flange Standard: ANSI, DIN, EN, GB, JIS (customizable according to international standards)
Flexibility Angle: ±15° (90-degree bending, adjustable within a small range)
Axial Displacement: ±10mm-±30mm (depending on diameter)
Radial Displacement: ±5mm-±15mm (depending on diameter)
Service Life: ≥10 years under normal working conditions

Product Categories : Rubber Expansion Joint > Elbow Rubber Expansion Joint
