Product Summary: Our Ss304 Chemical Pipeline Flexible Ptfe Rubber Expansion Joint is a high-performance corrosion-resistant solution. Combined with SUS304 material and PTFE lining, it offers excellent flexibility, sealing, and anti-corrosion. Ideal for chemical pipelines, it absorbs vibrations, compensates for displacements, and ensures stable operation, serving global industrial needs with reliable quality and certifications.
Product Overview
The Ss304 Flexible Ptfe Rubber Expansion Joint is a premium piping component designed for chemical and industrial applications. It integrates the corrosion resistance of PTFE with the flexibility of rubber, paired with high-quality SS304 stainless steel hardware to deliver exceptional performance in harsh environments. This corrosion resistant PTFE rubber expansion joint effectively absorbs axial, lateral, and angular displacements, reduces pipeline vibration and noise, and prevents media leakage, making it a core component for safe and efficient pipeline operation.
Technical Specifications
Core Material Details
- Main Body Material: High-quality rubber (EPDM/NBR optional), resistant to aging and high pressure
- Lining Material: Food-grade PTFE, corrosion-resistant to acids, alkalis, and organic solvents
- Flange Material: SS304 stainless steel (SUS316 optional), anti-rust and high-strength
- Working Pressure: 0.6MPa-2.5MPa
- Working Temperature: -20℃ to 120℃ (special customization for extreme temperatures available)
- Nominal Diameter: DN50-DN600 (custom sizes available)
- Connection Type: Flange connection (compliant with ANSI, EN, GB standards)
- Sealing Performance: Zero leakage under rated pressure
Product Features
Core Advantages
- Superior Corrosion Resistance: The PTFE lining ensures the joint resists most chemical media, including strong acids, alkalis, and oxidants, outperforming ordinary Rubber Joints in harsh chemical environments.
- High Structural Stability: SS304 Stainless Steel Flange enhances load-bearing capacity and rust resistance, extending service life compared to carbon steel flanged products.
- Excellent Flexibility: The rubber body provides good elasticity, effectively compensating for pipeline displacement caused by temperature changes and installation errors, reducing pipeline stress.
- Reliable Sealing: Integrated sealing structure with PTFE-rubber combination ensures zero leakage, avoiding media waste and safety hazards.
- Easy Installation: Lightweight design and standard flange connection simplify installation and maintenance, saving labor costs.
Product Principle
This
PTFE Lined Rubber Expansion Joint utilizes the elasticity of rubber to absorb pipeline displacements and vibrations, while the PTFE lining isolates the rubber from corrosive media, preventing rubber degradation. The SS304 flange ensures firm connection and structural stability, forming a comprehensive solution for chemical pipeline compensation and anti-corrosion.
How to Use the Product
Installation Steps
- Check the product appearance and dimensions to ensure they match the pipeline specifications, and confirm no damage during transportation.
- Clean the pipeline flange surface, removing oil, rust, and debris to ensure a tight seal.
- Align the joint flange with the pipeline flange, ensuring bolt holes are correctly positioned.
- Install bolts and nuts symmetrically, tightening them gradually with a torque wrench to ensure uniform force (avoid over-tightening to prevent flange deformation).
- After installation, conduct a pressure test to check for leakage; the joint can be put into use only if there is no leakage.
Application Scenarios
This product is widely used in various industrial fields requiring corrosion resistance and flexibility, bringing tangible value to customers:
- Chemical Industry: Suitable for pipelines transporting acids, alkalis, solvents, and other corrosive media in chemical plants, ensuring stable operation of reaction kettles, storage tanks, and conveying pipelines.
- Petrochemical Industry: Used in oil refining, chemical fertilizer, and petrochemical pipelines to resist corrosion of crude oil, chemical additives, and other media, reduce equipment vibration, and extend pipeline service life.
- Pharmaceutical Industry: Complies with food-grade standards, applicable to pharmaceutical production pipelines, ensuring no pollution to medicinal materials and meeting GMP requirements.
- Water Treatment Industry: Suitable for corrosive water treatment systems (such as sewage treatment, desalination), resisting the erosion of disinfectants and harmful substances.
- Electroplating Industry: Used in electroplating solution conveying pipelines, withstanding the corrosion of high-concentration electroplating chemicals, ensuring stable plating quality.
Customer Value
By choosing our corrosion resistant PTFE rubber expansion joint, customers can reduce maintenance frequency and replacement costs due to its long service life. The reliable sealing performance avoids production downtime caused by leakage, improving production efficiency. Meanwhile, the product’s compatibility with various media reduces the need for multiple types of joints, simplifying inventory management.
Customization Options
We offer personalized customization services to meet diverse customer needs:
- Size Customization: Nominal diameter, length, and flange size can be customized according to pipeline drawings.
- Material Customization: Rubber material (EPDM/NBR/Viton), flange material (SS304/SS316), and PTFE lining thickness can be adjusted.
- Pressure and Temperature Customization: Special designs for high-pressure (above 2.5MPa) and extreme temperature (-40℃ to 150℃) environments.
- OEM/ODM Services: Support brand customization, packaging design, and technical parameter optimization based on customer requirements.
Production Process
Our production process adheres to strict quality control, ensuring product consistency and reliability:
- Raw Material Inspection: Strictly test SS304 stainless steel, PTFE, and rubber raw materials to ensure they meet quality standards.
- Molding of Rubber Body: Adopt high-temperature vulcanization technology to form the rubber body, ensuring elasticity and density.
- PTFE Lining Processing: Precision bonding of PTFE lining to the rubber body, ensuring no delamination and uniform thickness.
- Flange Assembly: Weld or assemble SS304 flanges with the rubber body, ensuring structural firmness.
- Quality Testing: Conduct pressure testing, leakage testing, and appearance inspection on finished products; unqualified products are rejected.
- Packaging and Storage: Professional anti-corrosion packaging to avoid damage during transportation, with clear labeling for easy identification.
